Leviton – Certolux Visioneering (Viscor): LMNW Series LED Wide Commercial Wrap Luminaire
August 24, 2026
LMNW Series LED Wide Commercial Wrap Luminaire: An Ideal Choice for Commercial, Institutional & Utility Applications
When dependable row mounting performance and broad, uniform illumination are required, the LMNW wide commercial wrap delivers a practical solution for both renovation and new construction projects. Designed as a versatile commercial wrap, LMNW combines a wide footprint with a fully illuminated polycarbonate lens to provide smooth, even light distribution while helping simplify upgrades from older luminaires. Available in lengths from 24 to 96 inches, this fixture supports a range of lighting requirements and offers flexible installation options, making it an ideal choice for commercial, institutional, and utility applications.
The LMNW is engineered for environments where reliable, efficient illumination is essential. Its shallow-profile design helps create a clean appearance while delivering consistent lighting across stairwells, corridors, utility rooms, kitchens, and schools. The frosted polycarbonate lens is designed to provide low-glare illumination while resisting impacts, making the fixture suitable for demanding commercial environments. As a wide-body commercial wrap, the LMNW is especially effective when replacing existing luminaires because its larger footprint helps cover previous mounting locations and minimizes visual disruption during retrofits.
Installation versatility is another key advantage. LMNW supports both surface mount lighting and suspended lighting applications, allowing designers and contractors to select the mounting method that best suits the space. Mounting holes are strategically located to prevent housing distortion during installation, while offset mounting pads help keep the luminaire level and slightly separated from the mounting surface. For suspended applications, additional mounting points accommodate speedy hangers, S-hooks, aircraft cable systems, or stem-and-canopy mounting options. This flexibility helps streamline installation across a wide variety of ceiling conditions.
Built with a die-formed, code-gauge steel housing finished in high-reflectance white paint, the LMNW is designed for long-term durability and performance. The fixture also offers continuous Row Mounting capability, making it well suited for projects requiring uninterrupted runs of illumination. High-efficiency LEDs paired with dimmable 0-10V drivers provide quality lighting while achieving system efficacy of at least 100 lumens per watt. The luminaire is rated for L80 performance exceeding 50,000 hours, helping reduce maintenance requirements over the life of the installation. Suitable for both dry and damp locations, the LMNW is ETL certified to UL1598 and CSA standards, tested in accordance with IES LM-79, and RoHS compliant.
Whether specified for surface mount lighting in corridors or suspended lighting in open utility areas, the LMNW delivers dependable performance, installation flexibility, and long-lasting value. Its combination of wide-body coverage, durable construction, continuous row installation capability, and efficient LED technology makes it an excellent choice for projects seeking a reliable and cost-effective commercial lighting solution.
Features
- Continuous Row Mounting capability supports seamless runs of illumination across large spaces.
- Available in 24″, 48″, and 96″ lengths to accommodate a wide range of project requirements.
- Frosted polycarbonate lens delivers smooth, low-glare lighting while providing impact resistance.
- Supports both surface mount lighting and suspended lighting installations with multiple mounting options.
- High-efficiency LED system with 0-10V dimming, L80 performance over 50,000 hours, and suitability for dry and damp locations.
Product Specifications
- Application: Corridor, Stairways, Utility Area, Hallways, School
- Available Size(s): 24”, 48”, 96”
- Brand: VIS
- CRI: 80+
- Certification: cETLus Listed, IESNA LM-79, Damp Locations, RoHS Compliant, Maintainable
- Color Temperature: 3500K, 4000K Fixture
- Type: Surface, Strip, Wrap, Suspended
- Grade: Commercial Grade
- Light Source: LED
- Lumen Output: 3500-13500
- Market: Education, Commercial, Industrial, General Area
For more information on Leviton – Certolux Visioneering (Viscor) lighting solutions HERE
View original LinkedIn product post HERE
