Beta Calco: LE LOUVRE – Continuous Wall Luminaire
February 21, 2025
Beta Calco Introduces LE LOUVRE – Continuous Wall Luminaire
The striking new concept in louver technology is disrupting the linear lighting category and taking glare control to new heights with LE LOUVRE. Beta Calco’s award-winning design with diagonal cross-hatched construction of the louver in a soft concave shape provides not just visual comfort but a touch of panache unseen in traditional linear lighting. LE LOUVRE is available in white for higher performance, black for the highest glare control, and rich satinized finishes – chrome, gold, champagne, for elegant interior designs.
Tech Specs
- Body: Aluminum.
- Finish: Powder coated
- Drivers: HPF electronic drivers for 120-277V, 347V (EU-240V). The driver is integral to the fixture housing.
- Diffuser: Opal acrylic. 2.4″ width.
- PoE: Can be integrated into your data network via power over Ethernet (PoE) connectivity.
- BIOS: For circadian lighting, consult factory.
- Delivered Lumens: Delivered lumens & LPW based on 4000K CRI 80+
- Mechanical: Luminaires mount directly over J box (by others).
- Integral Emergency System: Emergency option provides a 1.5-hour (3 hours for EU) emergency lighting facility. The self-contained system includes the inverter module, NiCad batteries, LED charge indicator and test switch (NA only). Not available with a 347V supply.
- Sensors: Compatible with Avi-On, Casambi, Enlighted, Lutron Vive, nLight, NX Lighting Controls, Osram, Philips, and others. Consult factory.
- Reported L70 @25°C (77°F): > 60,000 hrs @ 2000 lumens/ft (6000 lumens/m)
- Estimated L70 @25°C (77°F): > 165,000 hrs @ 2000 lumens/ft (6000 lumens/m)
- Tunable White: Tunable White range from 2700K to 6500K is available; contact the factory for details.
- RGBW: RGBW available, consult factory.
- Approvals: Damp rated.
- Designed By: Serge Cornelissen.
- Design: US Pat. No. D959,043.
