Lux Sensors – CC-CES\x – CC-EDS Offerings From Cristal

Daylighting control photocell sensors (CES\I, CES\O, CES\A and CES\S) and the CCLK-1004 photocell controller provide indoor, outdoor, or skylight control of lighting circuits based on natural daylight. The Lux sensors and controller are able to provide coverage for any application. The photocell sensors light level measurements to an analog signal that is sent to Cristal room controller (CCLDIM) or the astronomical time clock (CCLK-1004) control module to control area lighting by switching banks of lights on and off or with 0-10V dimming.

Lux sensors are factory calibrated, and sensitivity is adjustable through the control module. The indoor sensor has a flat Fresnel lens that looks downward in a 60-degree cone of reference to measure actual light on the work surface. The outdoor sensor is enclosed in a weatherproof housing with a visor for shading and lens protection. The Atrium and Skylight sensors both use diffusing dome lenses to provide a 180-degree angle of photodiode response.


Lux Sensors Applications

  • Offices
  • Classrooms
  • Atriums
  • Commercial
  • Meeting rooms

Lux Sensors Features

CC-CESx

Accuracy+/-1% @ 21°C (70°F); Derated to +/-5% when above 49°C (120°F) or below 18°C (50°F)
Operating temperature-11°C to +60°C (-13°F to 150°F)
Wiring18/3AWG (600ft maxRed: Pos. +24VDC inputBlack: -24VDC commonYellow: 0-10VDC Output to CCLDIM or CCLK-1004 controller
Sensitivity ranges / size / mountingPreset minimum value, adjustable maximum value.
  • Multiple sensor options available.
  • Coverage is available for all daylight harvesting applications – indoor, outdoor, atrium and skylight.
Cat No.ApplicationMin.Factor. set max.Ajust. max.MountingOrient.HeightDia.
CES\IIndoor0 fc.100 fc.50-750 fc.Ceiling,max 10′Down2.00″1.23″
CES\OOutdoor0 fc.250 fc.50-750 fc.1/2″ IPTHoriz.1.85″1.28″
CES\AAtrium2 fc.1 000 fc.200-2500 fc.1/2″ IPTHoriz.2.25″1.28″
CES\SSkylight10 fc.5000 fc.1000-7500 fc.1/2″IPTUp2.25″1.28″

CC-EDS

Supplywith the low voltage source of an electronic dimming ballast T5 or T8.
Output0-10V
Range10-140fc
Factory calbrationFactory NIST traceable
On-site calibrationusing a 25 turn potentiometer with a range of 10 to 140fc.
StandardUL 916 Listed, Compliant with California Title 24
Warranty2 years
