Acclaim Lighting Introduces All-Weather Terra Drum with Multiple Color Options

Acclaim Lighting introduces the Terra Drum series, rugged, all-weather inground, drive-over ready rated fixtures designed for recessed façade and tree lighting applications.

Available in 15-, 30- and 60-watt versions, Terra Drums have a drive-over rating of up to 6,000 lbs. (2,721kg). They are offered in 2400K, 2700K, 3000K, 3500K, 4000K, Dynamic White (2700K-6000K), Quad Spectrum (RGBW, W=3000K), Quad White 4000K, and Quad White 6000K. The white version of the fixture produces up to 4000 lumens, while the color versions deliver up to 1800 lumens. The new fixtures offer beam angles of 10° x 10°, 10° x 60°, 25° x 25°, 30° x 60°, 40° x 40°, 60° x 60°, and 90° x 90°, and an asymmetric wall wash (60° x 60° + 20° tilt). Additionally, Acclaim Lighting’s Terra-Tilt adjuster allows users to fine-tune the beam position once each fixture is in place without compromising environmental protection.

The Terra Drum fixtures feature a die-cast aluminum housing with marine-grade coating, a glass top lens with an optional slip-resistant coating, and a 316L stainless steel trim ring finish for long-term performance. Optional black, white, brass or custom color trims are available. They are also available in a standard optic or 100% frosted glass, direct-view version.

Terra Drums can be quickly and easily daisy-chained in long runs using unified power and DMX control links. Fixture configuration is achieved using RDM over the control line. Terra Drums operate at 100-277VAC, 50/60 Hz, and have 0-100% dimming via DMX / RDM native, 0-10V (Sink) via an external ZDM-6, and DALI via an external DDC-1 AC.

IP68, IK10, and 3G rated with anti-theft security screws for almost any installation environment, Terra Drums perform in temperatures ranging from -40° F (-40°C) to 131° F (55°C). The fixture has a 150,000-hour performance life with a five-year limited warranty. For more information on Terra Drums, contact Acclaim Lighting at 323-213-4626 or visit http://acclaimlighting.com/terra-drum.

About Acclaim Lighting

Acclaim Lighting offers an impressive portfolio of innovative advanced solid-state lighting technology for dynamic architectural and commercial lighting products including linear, floods, downlights, direct view, tapes and tubes with high-performance control solutions. The experienced and well-trained Acclaim team provides extensive support worldwide, supporting lighting designers and architects to create leading distinctive lighting solutions to create reality for the customer’s vision.
